Smart-C
Light Weight. Cordless. Battery-Powered. Sophisticated Imaging Algorithm.
Smart-C
- Image Receptor—CsI scintillator on Complementary Metal Oxide Semiconductor (CMOS)
- Image Receptor Image Array—1.5k x 1.5k
- Image Receptor Pixel Size—~99 μm
- Field of View—
- Primary collimation: 15 x 15 cm (6 x 6 in)
- Secondary collimation: 10 cm (4 in) diameter
- Tube Voltage Range—40 to 80 kVp
- Tube Current Range—130 to 370 μA
- Pulse Rate—10 pulses per second
- Focal Spot—0.04 mm nominal
- Tablet Screen—34 cm (13.3 in) diagonal 1920 x 1080 resolution Touchscreen
- Live Image—15 cm x 15 cm (6 in x 6 in)
- Source to Detector Distance (SDD)—45 cm (17.7 in)
- Minimum Source to Skin Distance (SSD)—10 cm (4.0 in)
- C-Arm Free Space (Functional SSD)—34 cm (13.4 in)
- C-Arm Depth of Arc—31 cm (12.2 in)
- Networking—DICOM 3.0 compliant
- Wireless Security—WPA2 encryption
- Weights—
- C-arm and battery: 7.2 kg (16.0 lb)
- Tablet: 1.5 kg (3.3 lb)
- Footswitch: 0.7 kg (1.5 lb)
Monitor Cart
- Monitor—
- 27 in diagonal
- 1920 x 1080 resolution Touchscreen
- 725 Cd/m2
- Live Image—30 x 30 cm (12 x 12 in)
- Printer—Thermal, medical-grade
- Power—Battery operation (>8 hrs) or 115 VAC
- C-arm Battery Charge Bays—2
- Keyboard—Waterproof
- Weight—65 kg (143 lb)
Support Stand
- Height Adjustment Range—61 to 144 cm (24 to 57 in)
- Reach—116 cm (46 in)
- Horizontal Travel—218 cm (86 in)
- Orbital Arc Rotation—Counterbalanced 180°
- Wrist Spin Rotation—Unlimited
- Weight—75 kg (165 lb)
Orthoscan
New. Portable. Digital. Superb Image Quality.
- Fully Refurbished
- kV Range: 40 – 78kVp
- mA Range: 0.04 – 0.160mA
- Flat Detector
- 2 k x 1.5 k Image Resolution
- 15.0 cm x 12.0 cm Field Of View
OEC 6800
OEC, Best Refurbished Process and Service
C-Arm Specifications:
- Free Space: 12”
- Depth: 14.5”
- SID: 14.9”
- Orbit Rotation: 110 degrees
- Rotation: +/- 200 degrees
- Wig-Wag: 180 degrees
- Vertical Travel: 24”
- Extension: Up to 55”
